800W LLC Switching Power Supply Board for Power amplifier DIY +32V +36V +48V +/-32V +/- 40V +/-50V +/-60V +/-70V +/-80V ect for choose

Name: 800W LLC Switching Power Supply Board for Power amplifier DIY +32V +36V +48V +/-32V +/- 40V +/-50V +/-60V +/-70V +/-80V ect for choose
Brand: FYFAUDIO
SKU: 凯明800W 开关电源板--110V / Single 32VDC
Price: 60 USD
Availability: InStock

0.0 (0 Reviews)

~~$75.00~~ $60.00

Received successfully

Coupon Code

CONTINUE SHOPPING

Please select the information you want X

input voltage:

110V

220V
Output voltage:

Single 32VDC

Single 36VDC

Single 48VDC

Dual +/-32VDC

Dual +/-36VDC

Dual +/-40VDC

Dual +/-45VDC

Dual +/-50VDC

Dual +/-55VDC

Dual +/-60VDC

Dual +/-65VDC

Dual +/-70VDC

Dual +/-75VDC

Dual +/-80VDC

Dual +/-90VDC

Dual +/-100VDC

Other voltage

Quantity

Description

This product uses the LLCresonant half-bridge topology, with high conversion efficiency, low
interference, fast dynamic response, stable output voltage, etc., as well as integrated overcurrent, overvoltage, overtemperature, output short circuit protection,Is the bestcollocationof high-end power amplifier products. 200-800W power amplifier can be used, the 25-degree temperature continuous power 500W, peak power up to 1200W.

Input voltage: AC110V or 220V for choose

Output voltage:

Main voltage:

Type 1: Single voltage ( 2 wires output) +DC32V --- 70V all kinds voltage can provide.

Type 2: Dual Voltage ( 3 wires output) +/-32V----100V all kinds voltage can provide.

if the option is not have you needs voltage. you can choose"Other voltage" then send message to tell us the voltage that you need.

Auxiliary voltage:+/-12V 0.5A

Independent voltage:+12V 0.5A

Regulation accuracy: Main voltage no load ± 10%, with load ± 5%; , Auxiliary voltage/independent no load ± 15% with load ± 15% (at AC220V input, 400W load)

RMS power: 800W

Instantaneous power: 1200W (dynamic signal generated when the impact of power, time of less than 100 milliseconds)

Conversion efficiency: Max 95%

Use of the environment: -10 ~ 40 ℃

Storage temperature: -30 ~ 85 ℃

Dimensions: 80 * 148 * 45mm (W*L*H)
