PASS CRC 22000uF/35V Class A Amplifier Schottky MBR60200PT Rectifier Filter DIY Kit/Finished Board

Introduction:

This rectifier power supply board is suitable for pure Class A power amplifiers with independent power supply on the left and right sides. The left and right power supplies of the PCB are completely independent, with a mirror image design and thick wiring, which can withstand dozens of amperes of large current.

The rectifier part uses a high-current Schottky for rectification. Each tube has an output current of 30A. Each side of the positive and negative power supplies share 4 PCS tubes, and the entire board has 8 PCS high-current Schottky tubes. The large current capacity is very sufficient.

PCB Size: 210mm*145mm

Mounting capacitor diameter: 35mm

Rectifier tube model: MBR60200PT

Capacitors: 16 PCS Nichicon 22000uF/35V

NOTE: We have DIY kit or Finished board (Optional)

◆ DIY kit ---- All parts need you to solder and test it.

◆ Finished board ---- All parts have been welded and tested OK.
